| Parameter | Value |
|---|---|
| Peak output pulsed voltage | 450 V |
| Peak output pulsed current | 100 A |
| Input | 3 Phase ,415 Vac ±10%, 50 Hz |
| Pulse duration | 0.5 ms to 1 ms |
| Pulse top flatness | < 2% |
| Droop | < 2% |
| PRF | 2- 60 Hz (variable) |
| Pulse risetime | < 25 micro second |
| Current overshoot | 5.0% with settling time < 25 microsecond |
| Communication interface | RS 485 , 2 wire |
| Stability | 0.5% for 8 hour after 2 hours of warm up. |
| Local and Remote controls | ON/OFF, Fault reset, Current set, Voltage set, Remote/Local selection, Pulsewidth, Pulse Repetition Frequency |
| Protections | Line over and under voltage, Output over current, Output short circuit, Over temperature |
| Back panel BNC connectors for monitoring | Current Read back : 0-10V Voltage Read back : 0-10V |
| Programming | Fully programmable via RS 485 port |
| Size | 480 mm (W) x 300mm (H) x 520 mm(D) |
| Cooling | Forced air cooled |
